DZ47TR Transparent Small Circuit Breaker
Classification:
Product Introduction
DZ47TR transparent miniature circuit breaker is suitable for AC 50HZ, rated voltage 230V/400V, rated current 6-63A low-voltage terminal power distribution system With short circuit protection, overload protection, isolation and control functions.
Product Details
DZ47TR transparent miniature circuit breaker is suitable for AC 50HZ, rated voltage 230V/400V, rated current 6-63A low-voltage terminal power distribution system With short circuit protection, overload protection, isolation and control functions.
DZ47TR Transparent miniature circuit breaker has the following functions
Short circuit protection
Isolation function
Overload protection
| Electrical Characteristics | |
| Number of poles | 1P2P3P4P |
| Rated Current | 6,10,16,20,25,32,40,50,63A |
| Rated Voltage | 1P:230/400V-;2P-4P:400V~ |
| Breaking capacity | 6kA (C type 6-40A), 4.5kA (C type 50-63A, D type) |
| Rated impulse withstand voltage Uimp | 4kV |
| Rated insulation voltage Ui | 500V~ |
| Mechanical life | 20,000 times |
| Electrical life | 10,000 times |
| Reference calibration temperature | 30℃ |
| Terminal form | U-type terminal block |
| Maximum wiring capacity | 25mm² |
| Terminal Limit Torque | 2.5N.m |
| Inlet method | up-and-down feed |
| Standard | GB/T 10963.1 |
| Product certification | CCC |
| Tripping Characteristics | Type C (5In-10In), Type D (10In-20In) |
